Image / Intel® 1601A Memory Die, 1970

View source image on the Online Archive of California.

Get Citation

Have a question about this item?

Contact Owner

Item information. View source record on the Online Archive of California.

Title: Intel® 1601A Memory Die, 1970
Creator: Intel Corporation
Contributor: Intel Memory Dies
Date Created and/or Issued: 1970 1970
Publication Information: Intel Museum Archives
Contributing Institution: Intel Museum
Collection: Intel Museum Silicon Valley History Online Collection
Rights Information: Copyright ©Intel Corporation 1970. All Rights Reserved. Transmission and reproduction of a single copy of this work for non-commercial use in research or teaching in the United States is permitted if Intel is credited as the source of the work. The work must remain intact, as a complete whole and may not be combined with any other image or work to create a new document. Copyright ©Intel Corporation 1970. All Rights Reserved. Transmission and reproduction of a single copy of this work for non-commercial use in research or teaching in the United States is permitted if Intel is credited as the source of the work. The work must remain intact, as a complete whole and may not be combined with any other image or work to create a new document.
Description: Enlarged color photograph of the Intel® 1601A Memory Die. Fabricated with silicon gate technology; 256 word by 8 bit electrically programmable ROM suited for uses where fast turnaround and pattern experimentation were important such as in prototype or in one of a kind systems; factory reprogrammable which allowed Intel to perform a complete programming and functional test on each bit position before delivery; inputs and outputs DDT and TTL compatible; static and dynamic operation; the 1601 uses an identical chip related to 1602, 1701 and 1702.
Type: image
Format: 25 x 20 cm.
Identifier: http://ark.cdlib.org/ark:/13030/kt6q2nc8vt
cstcli 1998.51 - 260760
Language: English
Subject: Electronic industries; Memory dies; Photographs; Santa Clara (Calif.); Santa Clara County (Calif.)--History; Technology
Source: lcsh, local
